VapeSnail

VapeSnail for Billet Box and Boro Compatible AIOs

After release, two full years ago, the VapeShell has been a milestone for the Billet Box community. It took one step forward compared with other suggestions at that time, with its deck shape and airflow options, offering totally new potential for Billet Box users. The acceptance of the VapeShell has shown the way, so Atmizone’s bridge has added its little something to the Billet Box mania and the development of more Boro compatible AIOs over the past two years.
Only that, for us here in Atmizone lab, it is about time to get over the Boro/bridge concept. We bring you the VapeSnail, not another bridge but a complete RTA suggestion, bespoke to fit inside the Billet Box and Boro compatibles and ready to set a new paradigm to the world of AIOs.

RTA, not another bridge

The VapeSnail takes many steps forward, as it is much more than just another rebuildable bridge. Being an RTA with a custom dedicated tank of its own, it features real-time access to the deck and real-time ability to change the airflow tubes, plus a custom condensations plug with the optimal sealing ability and its own absorbent material, and many many more features you will love. Its tank is made of a special medical grade plastic called PCTG. It’s the same plastic that is used for approved baby bottles and medical appliances, FDA approved, totally safe and 100% resistant against cracker liquids. The tank hosts a large front port for refilling purposes, with a silicon cover which is easy to remove and replace in an instant. If you take the VapeSnail out of its AIO nest, and flip it upside down, you can have access to the deck in seconds, by just pulling the tank section off the Deck section. The deck features a huge space that is able to host many different approaches of one-coil rebuilding, from simple round wire to large exotic coils. The airflow of the VapeSnail is dialed in by a set of Positive Tubes with different inner diameters. By choosing your preferred inner diameter out of five fixed flow AFC Tubes (2.0/2.5/3.0/3.5/4.0mm inner D), you can have a tighter or more loose draw from loose MTL, RDL to a full open 4mm DL, having the air flow adjusted right under the coil. This largest one of the tubes also serves as a nest for a set of four pins to adjust to tighter air flow for MTL / loose MTL vaping. Most important, you can switch AFC Tube (and consequently MTL Pin as well) any time, even with full Tank and a build on the Deck. The Tubes not only control air flow right under coil but also serve as adjustable positive pole of the VapeSnail. Normally you screw them in all the way, but they can be adjusted lower if needed for use with certain Boro compatibles other than the Billet Box.  The versatility of the VapeSnail is further facilitated by an amazing part which also comes out of the box, the Chamber and Chimney Reducer. When in place, the CNC Reducer forms a restricted chamber and a narrow Chimney (2.5mm) suitable for MTL builds. When removed, the chamber opens up and the diameter of the chimney increases to 4.0mm, ready for open RDL / DL setups. The VapeSnail features its own condensations proofing design, with a custom Plug. The Plug is a custom silicon sealing gasket that helps so that you will have minimum condensations (if any) inside your AIO. Its sealing function is supported by the Absorbent Pad, a small round synthetic wick, easily replaceable, which absorbs any condensations piling up inside the air channel.

Features and Specs:

– Airflow tuning via 5 fixed AFC Tubes (pre-installed Pos. Tube with air hole D=4.0mm and alternative AFC Tubes 2/2.5/3/3.5mm) plus 4 MTL Pins (1/1.2/ 1.5mm/1.8mm pinned inside the Pos. Tube with D=4.0mm), all replaceable real-time with a full tank and rebuilt deck.
– M2.5mm pan head Phillips post screws.
– PCTG Tank allowing real-time access to Deck.
– 12.6mm post-to-post space, ~8.5mm post-to-post net space, ~8.0mm coil space.
– Max. net coiling height ~6.0mm (C & C Reducer out) / ~5.2mm (C & C Reducer in)
– Chimney inner D ~4.0mm (C & C Reducer out) / ~2.5mm (C & C Reducer in)
– Height 39.60mm [min] / Weight ~34g
